1

1” BSP – 17 JIC Elbow ZP

208-2-0059

3

2

Lubrication Hose Assy: Actuator to Pump

SAPH-017

1

3

Lubrication Hose Assy: Actuator to Pump

SAPH-016

1

4

1/8” Hex Head Plug Stainless Steel

202-6-0005

3

5

Sight Glass

500-21-0016

2

6

Lubrication Hose Assy: HE to Actuator

SAPH-019

1

7

Cooling Hose Assy: HE to Drain

SAPH-002

1

8

Lubrication Hose Assy: Filters to HE

SAPH-010

1

9

Cooling Hose Assy: Sol Valve to HE

SAPH-001

1

10

Ball Valve, ¾” BSP M/F

203-18-0036

4

11

1 ¼” – ¾” Reducing Bush

203-9-1210

6

12

1 ¼” BSP Female Tee

208-5-0001

2

13

¾” Plug

203-6-0750

1

14

1 ¼” Nipple

203-4-1250

3

15

Oil Filter Moisture Absorption 19µm

500-19-0057S

1

16

5.1” Filter Head

500-19-0055

2

17

Oil Filter Z-Glass Media 4µm

500-19-0056S

1

18

¾” BSP – 17 JIC Nipple

208-4-0073

3

19

1 ¼” BSP M/F Elbow

208-2-0057

1

20

¾” BSP – 17 JIC 45 Elbow ZP

208-4-0080

1

21

Heat Exchanger – 120 Plate

500-18-0098

1

22

¾” BSP – 17 JIC Elbow SS - Modified

208-2-0058-1

2

23

1 ¼” BSP – 17 JIC Nipple

208-1-0002

1

24

¾” BSP – 12 JIC Elbow SS - Modified

208-2-0052-1

1

25

Clamp Plate

SPS-08-3

1

26

M6 All Thread, 330mm

102-20-0330

4

27

½” BSP – 12 JIC Nipple

208-4-0081

1

28

½” Bulkhead

209-29-0010

2

29

½” BSP – 17 JIC Nipple

208-4-0082

1

30

½” Diaphragm Valve

205-17-0030

1

31

½” Nipple

203-4-0500

1

32

Lubrication Hose Assy: Pump to Filters

SAPH-018

1

33

¾” Strainer

203-11-0750

2

34

¾” BSP M/F Elbow

203-2-0030

2

35

1 ¼” – ¾” Male Reducer

203-8-0020

2

36

1” NPT – 1 ¼” BSP Nipple

208-4-0087

1

37

Oil Pump (1”)

500-7-0108

1

38

1” NPT – 17 JIC Elbow

208-2-0048

1

NA

Oil pump seal kit (1”)

500-7-0093

1

NA

Oil pump repair kit dual

500-7-0094

1

NA

Techni Syn-Gear EP150 20L Drum

500-3-0017

2
